10 Way Blade Fuse Box with LED - Spade Terminal
A convenient 10-way fuse block with integrated “fuse blown” indicator LEDs. The clear plastic cover allows you to quickly fault-find without disturbing your wiring. Includes convenient spade output connections for straight forward connections. Suitable for use in 12-24V systems, 30A max per fuse channel. Input cable up to 4-gauge. Uses standard automotive blade fuses, and includes a handy sheet of common labels, to make identification of connections even easier.
Features:
- Each fuse is numbered for easy installation & identification.
- Splash and dust-proof design.
- Sturdy and robust construction.
- The clear vibration resistant protective cover is securely held in place by means of a push latch system.
-
LED fuse blown indicator-When or if a fuse blows the red LED next to the problem fuse illuminates allowing for fast and hassle free identification of a fault.
- Input Terminal Rating: 32VDC @ 100A Max.
- Input Wire Size: 4-6 AWG
- Output Terminal Rating: 30A Max. per Circuit
- Output Wire Size: 12-16 AWG
- Fuses: Standard Automotive Blade Fuse up to 30A
| Positive common bus connection | M5 stud (5mm bolt) |
| Output connections | Standard 6.3mm spade terminals |
| Current rating per circuit / fuse | Up to 30 amp |
| Current rating per box | Up to 100 amp |
| Volt rating | 12V~32V |
| Temperature range | -20-125(℃) |
Product Dimension: 95mm(W) x 85mm(L) x 36mm(H)
Includes:
• 1 x 10 Gang Fuse Box
• 4 x 5A Fuse (Orange)
• 4 x 10A Fuse (Red)
• 4 x 15A Fuse (Blue)
• 4 x 20A Fuse (Yellow)
• 4 x 10A Fuse (Red)
• 4 x 15A Fuse (Blue)
• 4 x 20A Fuse (Yellow)
For wholesale enquiries, please contact sales@12vnation.co.za or 068 914 8816.
- R 320.00
- R 320.00
- Unit price
- per
Subtotal:
R 320.00
Couldn't load pickup availability
Description
xA convenient 10-way fuse block with integrated “fuse blown” indicator LEDs. The clear plastic cover allows you to quickly fault-find without disturbing your wiring. Includes convenient spade output connections for straight forward connections. Suitable for use in 12-24V systems, 30A max per fuse channel. Input cable up to 4-gauge. Uses standard automotive blade fuses, and includes a handy sheet of common labels, to make identification of connections even easier.
Features:
- Each fuse is numbered for easy installation & identification.
- Splash and dust-proof design.
- Sturdy and robust construction.
- The clear vibration resistant protective cover is securely held in place by means of a push latch system.
-
LED fuse blown indicator-When or if a fuse blows the red LED next to the problem fuse illuminates allowing for fast and hassle free identification of a fault.
- Input Terminal Rating: 32VDC @ 100A Max.
- Input Wire Size: 4-6 AWG
- Output Terminal Rating: 30A Max. per Circuit
- Output Wire Size: 12-16 AWG
- Fuses: Standard Automotive Blade Fuse up to 30A
| Positive common bus connection | M5 stud (5mm bolt) |
| Output connections | Standard 6.3mm spade terminals |
| Current rating per circuit / fuse | Up to 30 amp |
| Current rating per box | Up to 100 amp |
| Volt rating | 12V~32V |
| Temperature range | -20-125(℃) |
Product Dimension: 95mm(W) x 85mm(L) x 36mm(H)
Includes:
• 1 x 10 Gang Fuse Box
• 4 x 5A Fuse (Orange)
• 4 x 10A Fuse (Red)
• 4 x 15A Fuse (Blue)
• 4 x 20A Fuse (Yellow)
• 4 x 10A Fuse (Red)
• 4 x 15A Fuse (Blue)
• 4 x 20A Fuse (Yellow)
For wholesale enquiries, please contact sales@12vnation.co.za or 068 914 8816.
